DAEMO
Breaker & Quick Coupler
Daemo Breaker Alicon Series
| Model | Base Machine Weight(TON) | Suitable Kobelco Excavator | Operating Weight Top Box(KG) | Operating Weight Side Plate (KG) | Oil Flow Rate (L/MIN) | Impact Rate (H/Speed) (B/MIN) |
|---|---|---|---|---|---|---|
B30 |
2 - 4 |
SK35SR |
180 |
130 |
25 - 45 |
600 - 1100 |
B40 |
3 - 4.5 |
SK35SR |
224 |
162 |
30 - 50 |
500 - 1000 |
B50 |
3 - 8 |
SK50P |
333 |
271 |
30 - 55 |
350 - 900 (450 - 1000) |
B60 |
4 - 8 |
375 |
291 |
35 - 70 |
350 - 800 (450 - 1100) |
|
B70 |
5 - 8 |
SK75SR |
431 |
340 |
45 - 80 |
350 - 900 (450 - 1000) |
B90 |
6 - 9 |
SK75SR |
614 |
513 |
50 - 100 |
350 - 700 (550 - 950) |
B145 |
10 - 15 |
SK125SR, SK130 |
959 |
803 |
90 - 110 |
350 - 550 (500 - 750) |
B180 |
16 - 20 |
SK200 |
1209 |
1199 |
100 - 140 |
350 - 550 (500 - 750) |
B215 |
19 - 25 |
SK200, SK210LC |
1817 |
1726 |
110 - 160 |
350 - 500 (450 - 600) |
B235 |
18 - 25 |
SK200, SK210LC |
1856 |
1742 |
130 - 170 |
250 - 400 (350 - 500) |
B250 |
22 - 29 |
SK225SR |
2165 |
2020 |
150 - 210 |
250 - 350 (300 - 450) |
B300 |
26 - 32 |
SK330 |
2832 |
2796 |
180 - 250 |
200 - 350 (300 - 480) |
B360 |
28 - 36 |
SK330 |
2937 |
2806 |
180 - 250 |
200 - 350 (300 - 480) |
B450 |
40 - 50 |
SK520XDLC |
3713 |
3628 |
200 - 280 |
200 - 300 (300 - 450) |
B650 |
42 - 81 |
4380 |
- |
280 - 400 |
250 - 420 (300 - 500) |
|
B800 |
70 - 85 |
SK850 |
5625 |
- |
320 - 450 |
200 - 350 (250 - 400) |
B1000 |
70 - 120 |
5625 |
- |
380 - 455 |
300 - 475 |
Daemo Quick Coupler
| Model | Base Machine Weight(Ton) | Suitable Kobelco Excavator | Operating Weight (Kg) | Setting Pressure (KgF/cm2) | Oil Flow Rate (L/min) | Bucket Pin (mm) | Pin to Pin Distance (mm) |
|---|---|---|---|---|---|---|---|
DMQ35 |
4 |
SK35SR |
40 |
40 - 210 |
10 - 20 |
ø40 |
195 - 227 |
DMQ50 |
5 |
SK50P |
72 |
40 - 210 |
10 - 20 |
ø45 |
285 - 293 |
DMQ80 |
8 |
SK75SR |
92 |
40 - 320 |
10 - 20 |
ø55 |
285 - 328 |
DMQ140 |
14 |
SK125SR, SK130 |
184 |
40 - 380 |
10 - 20 |
ø65 |
380 - 448 |
FURUKAWA ROCK DRILL
Breaker
Furukawa Rock Drill Breaker
| Model | Base Machine Weight (Ton) | Suitable Kobelco Excavator | Operating Weight Top Box (Kg) | Oil flow rate (L/min) | Impact Rate (H/Speed) (B/min) |
|---|---|---|---|---|---|
HB20G Plus |
19 - 22 |
SK200, SK210LC |
1760 |
125 - 200 |
350 - 850 |
FXJ125 |
9 - 16 |
SK125SR, SK130 |
740 |
70 - 120 |
400 - 650 |
FXJ175 |
12 - 20 |
SK125SR, SK130 |
955 |
100 - 160 |
450 - 600 |
FXJ225 |
18 - 25 |
SK200, SK210LC, SK225SR |
1585 |
125 - 190 |
350 - 550 |
FXJ275 |
21 - 29 |
SK210LC, SK225SR |
1708 |
145 - 220 |
350 - 550 |
FXJ375 |
26 - 39 |
SK330 |
2449 |
170 - 260 |
300 - 450 |
FXJ475 |
35 - 55 |
SK520XDLC |
3100 |
200 - 300 |
250 - 350 |
FXJ770 |
44 - 75 |
4790 |
250 - 340 |
250 - 330 |
